L3 Firewall Update API automatically converting IP to CIDR

[Craiegg]

Hello all,

I am trying to update the L3 Firewall rules of a particular network via API for testing purposes, however whenever I enter the IP address I want in the Source and Destination it gets automatically converted to IP/subnet.

I have tested it with both v0 and v1 using Postman. Attaching the screenshot reference and the JSON data being passed to the API below. Do I need to switch the key from srcCidr to srcAddr and destCidr to destAddr? Any suggestions would be appreciated

  "rules": [

    {

        "comment": "Default rule",

        "policy": "allow",

        "protocol": "Any",

        "srcPort": "Any",

        "srcCidr": "Any",

        "destPort": "Any",

        "destCidr": "Any",

        "syslogEnabled": false

    },

    {

        "comment": "Testing rule",

        "policy": "allow",

        "protocol": "Any",

        "srcPort": "Any",

        "srcCidr": "192.168.128.56",

        "destPort": "Any",

        "destCidr": "2.2.2.9",

        "syslogEnabled": false

    }

  ]

}

[bmehta · Accepted solution]

Hello @Craiegg
In the dashboard configuration it does take only IP without subnet details. If on API it doesn't take only IP as an option the I believe this issue can be reported. However, for more information how does it converting to IP/subnet affecting your creating an issue. Thanks in advance.

[Craiegg]

Hello @bmehta , @PhilipDAth, @Bruce

Thank you for all your responses and suggestions.

Yes, there is no issue with the subnet being added. I was actually wondering if there was a change in the API, as when I used it last month, it took the IP address as is without conversion ( hence the query here ) .

However, I agree with all your suggestions of it not affecting anything if the subnet being added.

@bmehta  I will report this issue as it does not take only IP and always converts to subnet.

Thanks everyone.
Cheers,
Craig.

[Bruce]

I may be completely off track here, but if you're trying to specify a host for those two fields have you tried using the 'subnet mask' of /32, (i.e. 255.255.255.255), which is generally used to specify a host. For example, "srcCidr": "192.168.128.56/32" and "destCidr": "2.2.2.9/32".

[PhilipDAth]

192.168.128.56 and 192.168.128.56/32 are exactly the same thing.  /32 means it is a host IP address.
